LALIZAS Lifebuoy Ring SOLAS, with Retroreflective Tape
- Specially designed for commercial use.
- Ideal for cargo & passenger vessels.
- Available codes with SOLAS/MED and USCG SOLAS approvals.
- It features a hard, cross-linked polyethylene outer shell that does not deteriorate and is unaffected by extreme weather conditions.
- The grab line which surrounds the LALIZAS Lifebuoy Ring is designed to withstand oil and flames and provides easy & quick grab in case of emergency. Made of polyethylene.
- It is equipped with 400 sq.cm of SOLAS Retroreflective Tape (70180) that provides enhanced visibility in low light conditions.
- The highly visible colour of LALIZAS Lifebuoy Ring makes it easily detectable in water, through waves and fog.
- For maximum effectiveness, combine the Lifebuoy Ring with the Floating Line (70260) and the LALIZAS Lifebuoy Lights (70030/71325-6/196482).
*Impa Code
330151,330156,330157, 330158,330152, 330153,330154, 330155
| Code | Description | Height | Tested for operation with light & smoke signal | Resistant to flame & to diesel oil | Storage temperature | Highly visible colour | Grab line diameter (mm) | Grab line material | Lifebuoy shell / Internal material | Int.Diameter | Ext.Diameter | Drop Height (m) | Buoyancy (Nt) | Weight (kg) | Approval |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![[70090] LALIZAS Lifebuoy Ring SOLAS/MED-MER, w/Retroreflect.Tape, Ø73cm, 2.5Kg image](https://www.lalizas.com/images/items/itm_70090.jpg)
|
LALIZAS Lifebuoy Ring SOLAS/MED-MER, w/Retroreflect.Tape, Ø73cm, 2.5Kg | 90 mm +15mm, -5 mm | - | YES | -30oC up to + 65oC | YES | 9,5 | PE | HDPE / PU Foam | 440 mm ± 10 mm | 730 mm ± 15 mm | 80 | ≥ 145 Nt | 2.5 kg (5,51lb) | SOLAS/MED |
|
|
LALIZAS Lifebuoy Ring USCG SOLAS, w/Retroreflect.Tape, Ø73cm, 2.5Kg | 90 mm +15mm, -5 mm | - | YES | -30oC up to + 65oC | YES | 11 | PE | HDPE / PU Foam | 440 mm ± 10 mm | 730 mm ± 15 mm | 80 | ≥ 145 Nt | 2.5 kg (5,51lb) | USCG SOLAS |
|
|
LALIZAS Lifebuoy Ring SOLAS/MED-MER, w/Retroreflective Tape,Ø73cm, 4Kg | 90 mm +15mm, -5 mm | YES | YES | -30o C up to + 65o C | YES | 9,5 | PE | HDPE / PU Foam | 440 mm ± 10 mm | 730 mm ± 15 mm | 80 | ≥ 145 Nt | 4 kg (8,81lb) | SOLAS/MED |
|
|
LALIZAS Lifebuoy Ring USCG SOLAS, w/Retroreflective Tape,Ø73cm, 4kg | 90 mm +15mm, -5 mm | YES | YES | -30o C up to + 65o C | YES | 11 | PE | HDPE / PU Foam | 440 mm ± 10 mm | 730 mm ± 15 mm | 80 | ≥ 145 Nt | 4 kg (8,81lb) | USCG SOLAS |
